2018 IoT Security SolutionBlockchain security, Hardware is 'drawing attention'.

블록체인 보안 강화하면서 처리속도 높일 방법으로 관심
인텔·NEC·ICTK 등 하드웨어 기반 블록체인 개발·출시

[보안뉴스 오다인 기자] 블록체인 보안을 강화하면서 처리속도를 높일 방법으로 하드웨어 기반 기술이 부상하고 있다. 하드웨어 기반 블록체인 기술은 금융·물류·상거래 등에 블록체인을 실제 도입할 때 맞닥뜨리는 현실적인 문제점을 해결하는 대안으로 주목 받는 중이다.

[이미지=iclickart]

이는 현재 크게 3가지 방식으로 등장하고 있다. 첫째는 CPU 기반이다. CPU 보안 코드를 이용해 블록체인 소프트웨어의 보안을 높은 수준으로 유지하는 방식이다. 둘째는 보안 칩을 이용하는 방식이다. 개인 키 등 중요 정보를 보안 칩을 통해 보호함으로써 블록체인 보안을 강화한다. 셋째는 기존 하드웨어와 결합하는 형태다. 주로 스마트폰 같은 단말기 보안 기능을 활용한다.

인텔(Intel)은 CPU 기반 방식으로, 기존의 소프트웨어 가드 확장(Software Guard Extension, 이하 SGX) 기술을 이용해 블록체인과 인공지능(AI) 보안을 강화하는 중이다. SGX는 CPU 지시 코드들의 묶음으로, ‘엔클레이브(Enclave)’라고 불리는 보호된 영역에서 코드와 데이터의 선택적인 실행을 가능하게 해준다.

해외 IT 전문매체 CRN에 따르면, SGX는 원래 원격 컴퓨팅 보안과 웹 브라우징 보안, 디지털 저작권 관리 등을 위해 설계됐다. 이후 인텔은 SGX가 블록체인과 AI 워크로드에서 처리되는 민감 정보를 보호하는 데도 쓰일 수 있다는 사실을 발견했다.

인텔은 자사 블로그를 통해 “SGX가 하드웨어에 신뢰 실행 환경(Trusted Execution Environment, 이하 TEE)을 제공해주기 때문에 데이터의 사용·보존·이동 여부는 물론 보안을 강화해 주는 매우 강력한 기술”이라고 밝혔다. 또한 “빌트인 된 CPU 지시 코드들과 플랫폼 개선을 통해 데이터 접근이 허용된 코드에 대한 암호 어써션(cryptographic assertion)을 제공해준다”고 설명했다. “코드가 변경 또는 조작될 경우, 접근이 거부되고 환경 자체가 비활성화된다”는 것.

블록체인과 관련한 일례로, 인텔은 블록체인 스타트업 ‘에니그마(Enigma)’가 스마트 계약을 실행해 주는 프라이버시 프로토콜에 SGX를 사용함으로써 계약의 입력 데이터를 노출하지 않는다고 짚었다.

닛폰전기(NEC)도 인텔처럼 CPU 기반 방식의 기술을 선보이고 있다. 지난 2월 NEC는 노드 200개를 통해 초당 10만 건 이상의 데이터를 처리할 수 있다는 사실을 입증했다. 이에 대해 NEC는 TEE를 활용해 노드 간 합의를 형성, 필요한 통신 수를 획기적으로 낮췄기 때문에 가능한 일이었다고 설명했다.

아이씨티케이(ICTK)와 인트린식(Intrinsic)은 ‘PUF(Physical Unclonable Functions)’라는 보안 칩을 활용한다. 가드타임(Guardtime)은 2016년 인트린식의 PUF 칩을 이용해 이용자 인증과 관련한 블록체인 기술을 선보였다. IBM의 ‘크립토앵커(Crypto-Anchors)’와 삼성의 ‘아틱(ARTIK)’ 역시 하드웨어 기반 블록체인을 활용할 전망이다.


To read more:

https://www.boannews.com/media/view.asp?idx=70762&kind=3








Introduction to vertical business areas

Go >










Introduction to vertical business areas

Go >










Introduction to vertical business areas

Go >



We do these things.
PUF Technology



What is PUF?

Unique Inborn ID
(PUF, Physically Unclonable Functions)

•Silicon Inborn ID using the randomness of passive device generation in the semiconductor manufacturing process

• As a Physical ID created with physical characteristics, it is fundamentally impossible to falsify or duplicate the value

• Since each semiconductor chip generates a different unique ID, it is called a semiconductor fingerprint.

PUF Advantages

AS Via PUF provides unique Silicon Inborn ID characteristics,  It provides the Root of Trust (RoT), the source of all trust

•Via PUF guarantees stability that is impervious to
various types of hacking attacks.

•Via PUF is a method of forming via holes between
metal layers during semiconductor processing.

•As a passive device method, it is an innovative method
that solves all the problems of existing technologies.

•PUF that satisfies all randomness, homeostasis and
security •Unlike other technologies, no error correction
circuit (ECC) is required.

What you can do with PUF

VIA PUF can be applied to various IoT devices and solutions  that require strong security.

•ICTK's security chip generates a key pair of a private key and a public key in the security chip using an algorithm called ECC based on the key generated by PUF.

•ICTK's PUF security chip provides encrypted RAM (Random Access Memory) and encrypted eFlash (flash memory) inside.

•ICTK's security chip can be operated in PQC (Post Quantum Cryptography), a quantum security algorithm.

ICTK's security chip is the most powerful existing method to provide the Root of Trust function based on PUF.
